A shunt is an element that redirects electric current around another device. This can be used in many different types of electronics. Some of the most common applications are shunt diodes, circuit protection, and current measurement.
Shunts can be made from a wide variety of materials, including copper and aluminum. They can be designed to handle a wide range of current levels, from milliamperes to thousands of amperes.
There are a few different types of energy meter shunts, each with its own unique characteristics. These include:
Precision shunt: A precision shunt is an energy meter shunt that is designed for high accuracy and stability. It is usually used in industrial and commercial applications where precise current measurements are required.
Programmable shunt: A programmable shunt is an energy meter tsun that can be programmed to provide specific current measurements. It is often used in industrial and commercial applications where the ability to program the shunt is important.
The shunt is placed between a ground and a voltage divider. The voltages across the shunt and the divider are measured by an analog-to-digital converter (ADC).
There are many advantages to using shunts in energy meters. These include:
Low Resistance: Shunts are typically made of a high-conductivity material, such as copper or aluminum, which minimizes their resistance to ensure accurate current measurements.
They are also available in a variety of shapes and sizes, depending on the application.
This allows them to be easily integrated into the circuitry of an energy meter, and makes it possible to measure a wide range of currents.
Shunts are also easy to install, making them a cost-effective option for measuring electrical current in a large number of applications.
One of the main reasons for their popularity in the energy metering industry is that they are more accurate than Hall effect current sensors. This is because they don’t introduce a phase shift like CT, so the meter can be more accurately calibrated.
In addition, shunts are usually less expensive than CTs, which make them a good choice for many applications.
These shunts are able to detect voltage changes and current variations without introducing any phase shift, so they can be more accurately used in power quality monitoring, solar inverters, and other applications.
Shunts can also be used to detect and report leakage currents, which is a critical function for energy meters in industrial power systems. This allows the meter to identify and protect equipment from damage.
Other benefits of shunts in the energy metering industry are:
Complete Immunity to DC and AC Magnetic Fields: The ADC architecture of this new shunt device assures complete immunity to both DC and AC magnetic fields, so a power system’s electromagnetic interference does not interfere with the meter. This is not a problem in most of the world, but it can be a challenge in certain locations.
This is especially true in the United States and Canada, where EMI can be a major problem for energy meters.
